Fiberon PA12-CF10
Fiberon PA12-CF10
Experience exceptional engineering performance with Fiberon PA12-CF10 carbon fiber nylon filament, delivering low moisture professional nylon printing with superior dimensional stable composite excellence. This long chain copolyamide features 10% carbon fiber reinforcement, outstanding 131°C HDT, and revolutionary low moisture sensitivity compared to PA6/PA66 for consistent mechanical properties. Engineered with Warp-Free technology for moisture insensitive printing at 280-300°C without heated chambers, offering exceptional 3311 MPa Young's modulus and excellent chemical resistance. Trust this professional nylon composite for critical aerospace components, automotive parts, and composite manufacturing requiring precision dimensional stability and moisture-resistant excellence.
Key Features
-
Low Moisture Excellence exceptional sensitivity resistance compared PA6/PA66 guaranteed reliability
-
Professional Composite Performance 10% carbon fiber 131°C HDT dimensional precision certified
-
Warp-Free Technology moisture insensitive printing exceptional stability manufacturing ready guaranteed
-
Long Chain Copolyamide superior mechanical properties aerospace automotive applications proven
-
Dimensional Stable Engineering consistent performance humid environments professional durability assured
-
Easy Professional Printing 280-300°C no heated chamber user-friendly operation excellence
Fiberon PA12-CF10 is a carbon fiber reinforced long-chain copolyamide filament containing 10% chopped carbon fibers with a density of 1.06 g/cm³ and exceptional heat deflection temperature of 131°C at 0.45 MPa. This advanced composite exhibits superior mechanical properties with Young's modulus of 3311 MPa in X-Y direction when dry, thanks to its unique long-chain PA12 structure that provides significantly lower moisture sensitivity compared to PA6/PA66-based materials. The material features Warp-Free™ technology that ensures excellent dimensional stability with minimal shrinkage during printing and annealing processes.
Fiberon PA12-CF10 excels in aerospace, automotive, and composite manufacturing applications requiring high-performance parts with superior strength-to-weight ratios. It prints reliably on FDM systems with nozzle temperatures of 280-300°C and bed temperatures of 40-50°C, achieving printing speeds up to 300mm/s without requiring heated chambers or enclosures. Both professional engineers and advanced makers can leverage its outstanding dimensional stability and reduced moisture absorption for functional prototypes, end-use parts, and manufacturing tooling that demand precision and durability.
Users benefit from PA12-CF10's exceptional moisture resistance with only 1.5% equilibrium water absorption, maintaining 77.4 MPa tensile strength in dry conditions and 71.7 MPa when moisture conditioned. The material offers superior impact resistance with 10.2 kJ/m² Charpy impact strength and excellent z-axis properties through advanced Fiber-Adhesion technology. However, the abrasive carbon fibers limit brass nozzle life to approximately 9 hours, requiring hardened steel or ruby nozzles, and annealing at 100°C for 16 hours is strongly recommended to achieve maximum mechanical and thermal performance.
